DC POWER SUPPLY

ForceStart’s 28 VDC rectifiers, available in a range of capacities, deliver reliable and continuous DC power for civilian and military aircraft, helicopters, drones, and laboratory applications. Designed for both indoor and outdoor use, our units support on-board electrical systems during maintenance, repairs, installation, pre-flight checks, training, and testing—ensuring safe, efficient, and uninterrupted operations.


Enquiry Now
Specification
Input voltage(V) 220 +/-15 % or 380 +/-10%
Input frequency (Hz) 50 - 60
Input current (A) 8 - 64
Output voltage (V) 12; 24; 28; 36; 48
Output current (A) 50 - 1200
Max. output current (A) 65 - 1400
Output power(kW) 1,5 - 34
Max. ripple at the output (mV) 150
Monitoring devices voltmeter, ammeter
Operating temperature -50 +50
Dimensions (mm) 450х200х190 up to 600х305х505
Weight (kg) 7 up to 65

Frequently Asked Questions

The ForceStart DC Power Supply is a continuous rectifier designed to deliver stable 28VDC electrical power for civilian aircraft, military aircraft, helicopters, drones, and laboratory equipment. It is commonly used for aircraft maintenance, avionics testing, pre-flight checks, and ground support operations, ensuring reliable power for onboard electrical systems and aviation equipment.

Yes, the ForceStart aviation DC Power Supply is engineered for both indoor hangar maintenance and outdoor ground operations. It provides reliable power for aircraft repairs, system installations, diagnostics, and training activities, making it an essential piece of aircraft ground support equipment (GSE).

ForceStart provides a flexible DC Power supply range to meet various technical requirements. Our units offer output voltages including 12V, 24V, 28V, 36V, and 48V. Depending on the model, the DC Power supply can deliver an output current from 50A up to 1200A, with a maximum output power of up to 34 kW.

To ensure precision and safety, every ForceStart DC Power supply is equipped with dedicated monitoring devices, including a voltmeter and an ammeter. These tools allow ground crews to keep a close eye on the electrical output of the DC Power supply, ensuring the aircraft's sensitive electronics are receiving the correct levels of power.

Reliability in extreme environments is a hallmark of our equipment. The DC Power supply is designed to operate flawlessly in temperatures ranging from -50°C to +50°C. This wide operational window ensures that your DC Power supply remains functional in both arctic and desert climates without compromising performance.

Yes, the ForceStart DC Power Supply is widely used in laboratories, research facilities, and drone testing environments. With low ripple levels (maximum 150 mV) and stable current output, it provides precise electrical power for testing avionics components, UAV systems, and advanced aerospace electronics.

The ForceStart DC Power supply is designed to be as compact and portable as possible. Depending on the capacity, dimensions range from 450x200x190 mm to 600x305x505 mm. With weights starting as low as 7 kg up to 65 kg, it is easy to deploy the DC Power supply wherever it is needed on the airfield or in the workshop.
